Built - In Printer Leeb Portable Hardness Testing Equipment With RS232 / Large Memory
คุณสมบัติสินค้า:
Built - In Printer Leeb Portable Hardness Testing Equipment With RS232 / Large Memory
หมวดหมู่ : Brinell , เครื่องวัดความแข็ง , Durometer ,
Features:
● Large memory for 100 groups test results;
● Statistical data and upper-lower limit setting;
● Prints all test results and histogram;
● RS-232 interface (to hyperterminal or data view software);
● Time and date setting; auto-clock;
● Back-light LCD;
● Direct display of hardness scales HRB, HRC, HV, HB, HS, HL;
● Conversion to tensile strength σb (U.T.S.);
● For all metallic materials;
● Impact device provides testing at any angle, even upside down Integral thermal printer;
● High accuracy ±6HLD and conforms to ASTM A 956;
● Six impact devices are available for special applications.
| Product Name | Portable Leeb Hardness Tester | ||
| Model | iLeeb-300 | ||
| Hardness Scale | HL,HRC ,HRB, HRA, HV,HB,HS | ||
| Measuring Range | (170-960)HLD,(17-68.5)HRC,(19-651)HB,(80-976)HV,(30-100)HS,(59-85)HRA(13 -100)HRB | ||
| Measuring Direction | 0~360° | ||
| Indicating Error | HLD:±5; HRC:±1; HB:±4 | ||
| Memory | 500 Groups test maximum | ||
| Printer | Built-in Printer | ||
| Shell Material | Plastic | ||
| Statistics | Average value, min-max ,upper-lower limits | ||
| Data-Output | RS-232 | ||
| Impact Device | D (standard) | ||
| Optional impact Devices | DC/D+15/DL/G/C/E | ||
| Work piece radius (convex/concave) | Rmin=50mm(with support ring Rmin=10mm) | ||
| Min. Workpiece weight | 2~5kg on stable support 0.05~2kg with compact coupling except C and G impact device | ||
| Workpiece min. thickness couple | 5mm,expect with impact device G:10mm,C:1mm | ||
| Workpiece min. case hardened depth | 0.08mm except C impact device 0.2mm and impact device 1.2mm | ||
| Dimension | 212mm×72mm×30mm | ||
| Power Supply | AA6V,500mm(A1.8AV),A2.5~4hours | ||
| Operating Temperature | 0 ℃ to 40 ℃ | ||
| Weight | 280g (Excluding impact device and printer) |
